Chapter 22 DCU Setup (DCU)
1268
GPI Input Setting (GPI Input Assign Menu)
The action set in the following step 4 is executed for the switcher and DME
controlled by the selected control panel.
4
Using any of the following methods, select the action you want to set.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video cursor.
• Turn the knobs.
a) As for the setting values, see “Selectable actions for various trigger types” (page 1268)
b) When knob 2 selection is “Aux ? O’ride Src ??”
c) When knob 2 selection is “Key Snapshot”
d) When knob 2 selection is “Snapshot” or “Shotbox”
e) When knob 2 selection is “Macro”
f) When knob 2 selection is “Effect”
5
To confirm the setting in step 4, press [Action Set].
This confirms the setting, which appears in the status area.
Selectable actions for various trigger types
• When the trigger type is other than “Level”
M/E-1 Cut, M/E-2 Cut, M/E-3 Cut, P/P Cut,
M/E-1 Auto Trans, M/E-2 Auto Trans, M/E-3 Auto Trans,
P/P Auto Trans
M/E-1 Key1 Auto Trans, M/E-1 Key1 Cut
M/E-1 Key2 Auto Trans, M/E-1 Key2 Cut
M/E-1 Key3 Auto Trans, M/E-1 Key3 Cut
M/E-1 Key4 Auto Trans, M/E-1 Key4 Cut
M/E-2 Key1 Auto Trans, M/E-2 Key1 Cut
M/E-2 Key2 Auto Trans, M/E-2 Key2 Cut
M/E-2 Key3 Auto Trans, M/E-2 Key3 Cut
M/E-2 Key4 Auto Trans, M/E-2 Key4 Cut
M/E-3 Key1 Auto Trans, M/E-3 Key1 Cut
M/E-3 Key2 Auto Trans, M/E-3 Key2 Cut
M/E-3 Key3 Auto Trans, M/E-3 Key3 Cut
M/E-3 Key4 Auto Trans, M/E-3 Key4 Cut
P/P DSK1 Auto Trans, P/P DSK1 Cut
Knob Parameter Adjustment Setting values
2 Action Action selection
1 and upwards
a)
4 Aux Bus No AUX bus selection
1 to 48
b)
5 Reg No Register number
1 to 4
c)
1 to 99
d)
1 to 250
e)
1 to 399
f)
5 Src No Source signal selection
1 and upwards
b)
To Next Page
