Chapter 4 Keys
251
Key Setting Operations With the Key Control Block
• Separate edge on
The border width settings can be made independently for left, right, top, and
bottom sides. The separate edge function is only available when luminance
key, linear key, or chroma key is selected as the key type.
a) In the “4H mode” and when [Fine Key] (page 233) is on, the setting value range is 0 to 4.
To adjust the edge fill color
When [BDR] is selected, the [MORE] button lights amber. Pressing the
[MORE] button to turn it green then allows you to adjust the edge fill color
parameters with the knobs.
Setting the drop border or shadow parameters
When the [DROP BDR] or [SHDW] button is lit green, the parameter settings
differ between the “key drop OFF” and “key drop ON” modes (see page 211)
as shown below. Switching between these two modes is made by turning the
[KEY DROP] button on or off.
• “Key drop OFF” mode
a) In the “4H mode” and when [Fine Key] (page 233) is on, the setting value range is 0 to 4.
• “Key drop ON” mode
Knob Parameter Adjustment Setting values
1 Top Top edge width
0 to 8
a)
2 Left Left edge width
0 to 8
a)
3 Right Right edge width
0 to 8
a)
4 Bottom Bottom edge width
0 to 8
a)
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0 to 100
2 Saturation Saturation 0 to 100
3 Hue Hue 359 to 0
4 Density Density 0 to 100
Knob Parameter Adjustment Setting values
1Width Width
0 to 8
a)
2 Position Position 359 to 180
4 Density Density 0 to 100
Knob Parameter Adjustment Setting values
1Width Width
0 to 8
a)
