Sony MVS-8000 User Manual

Chapter 7 Frame Memory
397
Still Image Operations
a) The patterns are the same as for a standard wipe. See “Wipe Pattern List” in Appendix
(Volume 1) (page 522).
• When [Ext Key] is selected
• When [Mix] is selected
3 When you selected a pattern key, press [Pattern Adjust].
The Pattern Adjust menu appears. In the menu, set the pattern modifiers as
required.
• When turning [Position] on and setting the pattern position
a) See page 302.
• When turning [Multi] on and replicating the pattern
a) See page 307.
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See page 306.
3 Pattern Pattern number
1 to 24
a)
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 Clip Reference level for key
signal generation
+109.59 to –7.31
2 Gain Key sensitivity –100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Mix Rate Mix proportion 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Position H Horizontal position
–100.00 to +100.00
a)
2 Position V Vertical position
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of
pattern horizontally
1 to 63
2 V Multi Number of repetitions of
pattern vertically
1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio
–100.00 to +100.00
a)
