Clock Commands 121
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\Clock.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Polling time is configured with the sntp client poll timer Global
Configuration mode command.
The format of an IPv6Z address is: <
ipv6-link-local-address>%<interface-
name
>.
interface-name =
vlan<integer> | ch<integer> | isatap<integer> |
<physical-port-name> | 0
integer = <
decimal-number> | <integer><decimal-number
>
decimal-number =
0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9
physical-port-name = Designated port number, for example:gi1/0/16.
If the egress interface is not specified, the default interface is selected.
Specifying interface zone=0 is equal to not defining an egress interface.
Example
The following example configures the device to accept SNTP traffic from the
server on 192.1.1.1.
Console(config)#
sntp server
192.1.1.1
sntp port
The sntp port Global Configuration mode command specifies a Simple
Network Time Protocol (SNTP) User Datagram Protocol (UDP) port. Use
the no form of this command to use the SNTP server default port.
Syntax
sntp port
port-number
no sntp port
Parameters
port-number—Specifies the UDP port number used by an SNTP server.
(Range 1–65535)
Default Configuration
The default port number is 123.
