514 VLAN Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\VLAN_ISCLI_Only.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
•
remove
—Clears the association between a secondary VLAN and a primary
VLAN.
•
secondary-vlan-list
—Specifies one or more secondary VLANs to be
associated with a primary VLAN in a private VLAN.
Default Configuration
No private VLANs are configured.
Command Mode
Interface Configuration (VLAN) mode
User Guidelines
• The command can only be executed in the context of the primary VLAN.
• Private VLAN cannot be removed or change its type if it is associated with
other private VLANs.
• Primary VLAN can be associated with only single isolated VLAN.
• A secondary VLAN can be associated with only one primary VLAN.
• The association of secondary VLANs with a primary VLAN cannot be
removed if there are private VLAN ports that are members in the
secondary VLAN.
• In MSTP mode, all the VLANs that are associated with a private VLAN
should be mapped to the same instance.
switchport private-vlan mapping
Use the switchport private-vlan mapping Interface Configuration mode
command to configure the VLANs of the private-vlan promiscuous port. Use
the no form of this command to reset to default.
Syntax
switchport private-vlan mapping
primary-vlan-id [add | remove] secondary-
vlan-list
no switchport private-vlan mapping
