352 PHY Diagnostics Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\Phy_Diagnostics.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Can't perform the test on fiber ports
show cable-diagnostics tdr
Use the show cable-diagnostics tdr EXEC mode command to display
information on the last Time Domain Reflectometry (TDR) test performed
on all copper ports or on a specific copper port.
Syntax
show cable-diagnostics tdr [ interface interface-id ]
Parameters
interface-id—Specifies an interface ID. The interface ID must be an
Ethernet port.
Command Mode
EXEC mode
User Guidelines
The maximum length of cable for the TDR test is 120 meters.
Example
The following example displays information on the last TDR test performed
on all copper ports.
Console> show cable-diagnostics tdr
Port
----
Result
---------
Length [meters]
--------------
Date
---------------------
gi1/0/1 OK
gi1/0/2 Short 50 13:32:00 23 July 2010
gi1/0/3 Test has not been performed
gi1/0/4 Open 64 13:32:00 23 July 2010
gi1/0/5 Fiber - -
