502 VLAN Commands
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\VLAN_ISCLI_Only.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Example
The following example configures a VLAN ID of 23 to the untagged layer 2
VLAN gigabitethernet port
1/0/ 1.
Console(config)# interface gigabitethernet 1/0/1
Console(config-if)# switchport access vlan 23
switchport access multicast-tv vlan
Use the switchport access multicast-tv vlan Interface Configuration
(Ethernet, Port-channel) mode command to enable receiving multicast
transmissions from a VLAN that is not the Access port VLAN, while keeping
the L2 segregation with subscribers on different Access port VLANs. Use the
no form of this command to disable receiving multicast transmissions.
Syntax
switchport access multicast-tv vlan vlan-id
no switchport access multicast-tv vlan
Parameters
vlan-id—Specifies the Multicast TV VLAN ID.
Default Configuration
Receiving multicast transmissions is disabled.
Command Mode
Interface Configuration (Ethernet, Port-channel) mode
User Guidelines
The user cannot transmit multicast transmissions on the multicast TV
VLAN.
A multicast TV VLAN cannot be enabled if a Guest VLAN is enabled on the
interface.
