Dell PowerConnect PC5524 User Manual

VLAN Commands 511
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\CLI Folders\Dell Contax
CLI\files\VLAN_ISCLI_Only.fm
DELL CONFIDENTIAL – PRELIMINARY 5/15/12 - FOR PROOF ONLY
Parameters
• protocol —Specifies a 16-bit protocol number or one of the reserved names
listed in the User Guidelines. (Range: 0x0600–0xFFFF)
•
encapsulation —Specifies one of the following values: Ethernet, rfc1042,
llcOther. If no option is indicated, the default is Ethernet.
•
protocols-group group —Specifies the group number of the group of
protocols associated together. (Range: 1–2147483647)
Default Configuration
The default encapsulation is Ethernet.
Command Mode
VLAN Configuration mode
User Guidelines
The value 0x8100 is not valid as the protocol number for Ethernet
encapsulation.
The following protocol names are reserved for Ethernet Encapsulation:
•ip
•arp
•ipv6
•ipx
Example
The following example maps protocol ip to protocol group number 213.
Console(config)# vlan database
Console(config-vlan)# map protocol ip protocols-group 213
switchport general map protocols-group vlan
Use the switchport general map protocols-group vlan Interface
Configuration (Ethernet, Port-channel) mode command to set a protocol-
based classification rule. Use the no form of this command to delete a
classification.
