9-105
Command Line Reference
Wireless Interface Commands
Command Mode
WLAN Interface Configuration
Command Usage
• When closed system is enabled, stations with a configured SSID of
"any" are not able to associate with the access point.
Example
mode
This command sets the wireless mode for the interface.
Syntax
mode <a | b | g>
• a - 802.11a stations operate in the 5 GHz U-NII band using orthogonal
frequency division multiplexing (OFDM). It supports data rates
ranging from 6 to 54 Mbps. Supported only on the access point’s
second radio (radio2).
• b - 802.11b stations include 5.5 Mbp and 11 Mbps data rates. It uses
direct sequence spread spectrum (DSSS) or frequency hopping
spread spectrum (FHSS) in the 2.4 GHz ISM band as well as comple-
mentary code keying (CCK) to provide the higher data rates. It
supports data rates ranging from 1 to 11 Mbps. Supported on both
the access point’s radios (1 and 2).
• g - 802.11g stations operate at a higher speed extension (up to 54
Mbps) to the 802.11b PHY while operating in the 2.4 GHz band. It uses
orthogonal frequency division multiplexing (OFDM). It supports data
rates ranging from 1 to 54 Mbps. Supported on both the access
point’s radios (1 and 2). By default 802.11g supports 802.11b.
Default Setting
g
Command Mode
ProCurve Access Point 530# configure
ProCurve Access Point 530(config)# radio 1
ProCurve Access Point 530(radio1)# wlan 1
ProCurve Access Point 530(radio1-wlan1)# closed-system
ProCurve Access Point 530(radio1-wlan1)#
