B2410 • B271 0 •
82910
WSM, 12271
00000F10410
00000F10420
1 ENGINE
Oil Clearance between Crankshaft Journal and Crankshaft
Bearing 1
1.
Measure the O.D. of the crankshaft front journal with
an
outside
micrometer.
2.
Measure the I.D. of the crankshaft bearing 1 with
an
inside
micrometer, and calculate the oil clearance.
3.
If
the oil clearance exceeds the allowable limit, replace the
crankshaft bearing 1.
4.
If
the same size bearing
is
useless because of the crankshaft
journal wear, replace it with an undersize one referring to the
table and figure.
Factory spec.
0.034 to 0.114 mm
Oil clearance between
0.00134 to 0.00449 in.
crankshaft journal and
crankshaft bearing 1
Allowable limit
0.20 mm
0.0079 in.
Crankshaft journal
0.0.
Factory spec.
47.934 to 47.950 mm
1.88716 to 1.88779 in.
Crankshaft bearing 1
1.0.
Factory spec.
47.984 to 48.048 mm
1.88913 to 1.89165 in.
(Reference)
• Undersize crankshaft bearin"g 1
00000F10430
Undersize Bearing
Code Number
Marking
0.2mm
Crankshaft bearing 1
16241-23911 020 US
0.008 in.
02
0.4 mm
Crankshaft bearing 1
16241-23921
040 US
0.016 in.
04
• Undersize dimensions of crankshaft journal
~
0.2mm
O.4mm
Dimension
0.008 in. 0.016 in.
A
2.3 to 2.7
mm
radius 2.3 to 2.7 mm radius
0.0906
to
0.1063 in.radius 0.0906 to 0.1063 in.radius
B
1.0 to 1.5 mm radius 1.0 to 1.5 mm radius
0.0394
to
0.0591 in. radius
0.0394 to 0.0591 in. radius
C
47.734
to
47.750
mm
47.534 to 47.550 mm
1.87929
to
1.87992 in. 1.87142 to 1.87204 in.
The crankshaft journal
must
be fine-finished
to
higher than
~v~~).
00000810331
Replacing Crankshaft Bearing 1
(When removing)
1.
Press out the used crankshaft bearing 1 using a crankshaft
bearing 1 replacing tool.
(When installing)
1.
Clean a new crankshaft bearing 1 and crankshaft journal bore,
and apply engine oil
to
them.
2.
Using a crankshaft bearing 1 replacing tool, press
in
a new
bearing 1 (2) so that its seam (1) directs toward the exhaust
manifold side. (See figure)
00000F10440
(A)
2
3
Dimension (A) Factory spec.
oto 0.3
mm
oto 0.0118 in.
(1) Seam
(2) Crankshaft Bearing 1
1-S45
(3) Cylinder Block
00000810341
