B2410 • B2710 •
B291
0 WSM,
12271
3 TRANSMISSION
Mid-PTa Shaft
1.
Remove the spring
(1)
and ball
(2).
2.
Draw out the dowel pin and remove the shift arm (3) with shifter
(4).
3.
Remove the oil seal
(5)
and internal snap
ring
(6).
4.
Remove the mid-PTa shaft
(7)
with
11
T shifter gear
(8)
and
bearings (9).
(When reassembling)
• Apply grease to lip and outer of oil seal.
(1)
Spring
(6)
Internal Snap Ring
(2)
Ball
(7)
Mid-PTa Shaft
(3)
Shift
Arm
(8)
11
T Shifter Gear
(4)
Shifter
(9)
Bearing
(5)
Oil Seal
12270F30160
12270$30270
39.2 to
44.1
N'm
Tightening torque
PTa
cover mounting screw
4.0 to 4.5 kgf·m
28.9 to 32.5 ft-Ibs
12270$30280
2270P30250
[5] DISASSEMBLING DIFFERENTIAL GEAR CASE
PTa
Shaft
1.
Remove the
PTa
cover mounting screws and remove the
PTa
cover assembly.
(When reassembling)
• Apply liquid gasket (Three Bond 12080 or equivalent) to joint
face of differential gear case and
PTa
cover.
12270P30260
3
Differential Gear Assembly
1.
Remove the bearing holder mounting screws and remove the
bearing holder (1).
2.
Take out the differential gear assembly (3).
(When reassembling)
• Install the differential gear assembly, noting the number of shims
(2)
in
the differential case left side and bearing holder side.
Differential gears bearing
17.7 to 20.6
N·m
Tightening torque 1.8 to
2.1
kgf·m
holder mounting screw
13.0 to 15.2 ft-Ibs
(1)
Bearing Holder
(2)
Adjusting Shim
(3)
Differential Gear Assembly
12270$30290
3-S27
