82410 • 82710 • 82910
WSM,
12271
G GENERAL
• Clamp wIring so that there
is
no twist, unnecessary sag, or
excessive tension, except for movable part, where sag be
required.
(A)
(B)
(1) Wiring
(2)
Clamp
(A) Correct
(B) Incorrect
11790F00120
(A)
11790F00130
11790F00140
(2)
Battery
11790GOO1
00
•
In
installing a part, take care not to get wiring caught by
it.
(1)
Wiring (A) Incorrect
11790G00110
• After installing wiring, check protection of terminals and clamped
condition of wiring, only connect battery.
(1)
Cover
• Securely Install Cover
11790GOO120
11790F00060
• Take care not to confuse positive and negative terminal posts.
• When removing battery cables, disconnect
negative cable first.
When installing battery cables, check for polarity and connect
positive cable first.
• Do not install any battery with capacity other than
is
specified
(Ah).
• After connecting cables to battery terminal posts, apply high
temperature grease to them and securely install terminal
covers
on them.
• Do not allow dirt and dust
to
collect on battery.
A CAUTION
• Take care
not
to
let
battery
liquid
spill
on
your
skin
and
clothes.
If
contaminated,
wash
it
off
with
water
immediately.
•
Before
recharging
the
battery, remove
it
from
the
machine.
•
Before
recharging,
remove
cell caps.
• Do
recharging
in
a well-ventilated
place
where
there
is
no
open
flame
nearby,
as
hydrogen
gas
and
oxygen
are
formed.
11790G00131
G-5
