Configure System Information
111
M4100 Series Managed Switch
View ISDP Neighbors
 To view ISDP neighbors:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select System
 ISDP  Advanced  Neighbor.
The following table describes the ISDP Neighbor fields.
Table 34. ISDP Neighbor
Field Description
Device ID The device ID of the ISDP neighbor.
Interface The interface on which the neighbor is discovered.
Address Displays the address of the neighbor.
