NETGEAR M4100 Series User Manual

Configure Switching Information
137
M4100 Series Managed Switch
• Disable. The default value.
• None. Allow the IP phone to use its own configuration to send untagged voice traffic.
• VLAN ID. Configure the phone to send tagged voice traffic.
• dot1p. Configure voice VLAN 802.1p priority tagging for voice traffic. When this is
selected, enter the dot1p value in the Value field.
• Untagged. Configure the phone to send untagged voice traffic.
11. Use Value to enter the VLAN ID or dot1p value.
This is enabled only when VLAN ID or dot1p is selected as interface mode.
12. Use CoS Override Mode to select the Cos override mode for selected interface.
The default is Disable.
Configure GARP Switch Settings
Note: It can take up to 10 seconds for GARP configuration changes to take
effect.
 To configure GARP switch settings:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
