NETGEAR M4100 Series User Manual

Manage Device Security
366
M4100 Series Managed Switch
user, a sequence number that is one greater than the highest sequence number currently
in use for this interface and direction is used. The valid range is 1–4294967295.
10. Click the appropriate orange bar to expose the available ports or LAGs. The Port Selection
Table specifies list of all available valid interfaces for ACL mapping. All non-routing physical
interfaces and interfaces participating in LAGs are listed.
• T
o add the selected ACL to a port or LAG, click the box directly below the port or LAG
number so that an X appears in the box.
• T
o remove the selected ACL from a port or LAG, click the box directly below the port
or LAG number to clear the selection. An X in the box indicates that the ACL is
applied to the interface.
11. Click the APPLY button.
Your settings are saved.
The following table describes the nonconfigurable information displayed on the screen.
Table 96. IP Binding Configuration
Field Description
Interface The selected interface.
Direction The selected packet filtering direction for ACL.
ACL Type The type of ACL assigned to the selected interface and direction.
ACL ID/Name The ACL number (in the case of an IP ACL) or ACL name (in the case
of named IP
ACL and IPv6 ACL) identifying the ACL assigned to the
selected interface and direction.
Sequence Number The sequence number signifying the order of specified ACL relative to
other
ACLs assigned to the selected interface and direction.
View or Delete IP ACL Bindings
 To view or delete the IP ACL bindings:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
