NETGEAR M4100 Series User Manual

Manage Device Security
354
M4100 Series Managed Switch
7. Select Security  ACL > Basic  Binding Table.
To delete a MAC ACL-to-interface binding, select the check box next to the interface and click
the DELETE button.
The following table describes the information displayed in the MAC Binding Table.
Table 94. MAC Binding Table
324 Field Description
Interface The interface of the ACL assigned.
Direction The selected packet filtering direction for the ACL.
ACL Type The type of ACL assigned to the selected interface and direction.
ACL ID The ACL name identifying the ACL assigned to the selected interface
and direction.
Sequence Number The sequence number signifying the order of the specified ACL relative
to the other
ACLs assigned to the selected interface and direction.
Configure an IP ACL
An IP ACL consists of a set of rules that are matched sequentially against a packet. When a
packet meets the match criteria of a rule, the specified rule action (Permit/Deny) is taken and
the additional rules are not checked for a match.
 To configure an IP ACL:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
