NETGEAR M4100 Series User Manual

Configure System Information
24
M4100 Series Managed Switch
• Service Port
• Different . Some applications that can be selected in this screen require that the
source interface be configured separately
. In this case, the Different option is
shown.
By default VLAN 1 is used as the source interface.
9. Click the APPLY button.
The settings are sent to the switch. Configuration changes take effect immediately. These
changes are not retained across a power cycle unless you save the configuration. See
Save Configuration on page 405.
The following table describes the status information the System screen displays.System
Information
Table 3. Status information in the System screen
Field Description
Product Name The product name of this switch.
IPv4 Management VLAN Interface The IPv4 address and mask assigned to the management VLAN
interface.
Management VLAN ID The management VLAN ID of the switch. Click the displayed
Management VLAN ID value to jump to the VLAN screen.
IPv4 Loopback Interface The IPv4 address and mask assigned to the loopback interface.
System Date The current date.
System Up time The time in days, hours, and minutes since the last switch reboot.
Current SNTP Sync Status Displays the current SNTP sync status.
System SNMP OID The base object ID for the switch's enterprise MIB.
System Mac Address Universally assigned network address.
Supported Java plug-in Version The supported version of Java plug-in.
Current SNTP Synchronized Time Displays the SNTP synchronized time.
View the Switch Status
You can view the fan status, temperature status, device status, and switch statistics.
View the Fan Status
You can view the status of the fans in all units. These fans remove the heat generated by the
power, CPU, and other chipsets, and allow the chipsets work normally.
