NETGEAR M4100 Series User Manual

Manage Device Security
367
M4100 Series Managed Switch
6. Click the Login button.
The web management interface menu displays.
7. Select Security
 ACL> Advanced  Binding Table.
8. To delete an IP ACL-to-interface binding, select the check box next to the interface and click
the DELETE button.
The following table describes the information displayed in the IP
ACL Binding Table.
Table 97. IP ACL Binding Table
Field Description
Interface The selected interface.
Direction The selected packet filtering direction for the ACL.
ACL Type The type of ACL assigned to the selected interface and direction.
ACL ID/Name The ACL number (in the case of an IP ACL) or ACL name (in the case
of a named IP
ACL and IPv6 ACL) identifying the ACL assigned to the
selected interface and direction.
Sequence Number The sequence number signifying the order of specified ACL relative to
other
ACLs assigned to the selected interface and direction.
View or Delete VLAN ACL Bindings
You can view or delete the VLAN ACL bindings.
 To view or delete VLAN ACL bindings in the VLAN Binding Table:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
