Routing
231
M4100 Series Managed Switch
This appears only if the user selects Specific Dynamic/Gateway Entry or Specific
Static Entry in the Remove from Table list.
The following table describes the nonconfigurable information displayed on the screen.
Table 71. ARP Table Configuration
Field Description
Total Entry Count Total number of entries in the ARP table.
Peak Total Entries Highest value reached by Total Entry Count. This counter value is
restarted whenever the
ARP Table Cache Size value is changed.
Active Static Entries Total number of active static entries in the ARP Table.
Configured Static Entries Total number of configured static entries in the ARP Table.
Maximum Static Entries Maximum number of static entries that can be defined.
Configure Router Discovery
 To configure router discovery:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
