Routing
216
M4100 Series Managed Switch
The following table describes the nonconfigurable information displayed on the screen.
Table 67. IP Configuration
Field Description
Default Time to Live The default value inserted into the Time-To-Live field of the IP header of
datagrams originated by the switch, if a
TTL value is not supplied by the
transport layer protocol.
Maximum Next Hops The maximum number of hops supported by the switch. This is a
compile-time constant.
Maximum Routes The maximum number of routes (routing table size) supported by the
switch.
This is a compile-time constant.
View IP Statistics
The statistics reported on this screen are as specified in RFC 1213.
 To view the IP statistics:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Routingï€
 IP  Advanced  IP Statistics.
