NETGEAR M4100 Series User Manual

Configure Switching Information
148
M4100 Series Managed Switch
connected to hosts that typically drop BPDUs. If an operational edge port receives a
BPDU, it immediately loses its operational status. In that case, if BPDU filtering is enabled
on this port then the BPDUs received on this port are dropped.
The following table describes the nonconfigurable information displayed on the screen.
Table 42. STP Configuration
Field Description
Configuration Digest Key Identifier used to identify the configuration currently being used.
MST ID Table consisting of the MST instances (including the CST) and the
corresponding VLAN IDs associated with each of them.
VID ID Table consisting of the VLAN IDs and the corresponding FID
associated with each of them.
FID ID Table consisting of the FIDs and the corresponding VLAN IDs
associated with each of them.
Configure Advanced STP Settings
 To configure advanced STP settings:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
