Configure System Information
95
M4100 Series Managed Switch
View LLDP Local Device Information
 To view LLDP local device information:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select System
 LLDP  Local Device Information.
8. Use Interface to specify the list of all the ports on which LLDP - 802.1AB frames can be
transmitted.
The following table describes the LLDP Local Device Information fields.
Table 26. LLDP Local Device Information
Field Description
Chassis ID Subtype Specifies the string that describes the source of the chassis identifier.
Chassis ID Specifies the string value used to identify the chassis component
associated with the local system.
