NETGEAR M4100 Series User Manual

Configure Switching Information
121
M4100 Series Managed Switch
The web management interface menu displays.
7. Select Switching
 VLAN  Basic  VLAN Configuration.
8. Use VLAN ID to specify the VLAN Identifier for the new VLAN.
The range of the VLAN ID is 1 to 4093.
9. Use the optional VLAN Name field to specify a name for the VLAN.
It can be up to 32 alphanumeric characters long, including blanks. The default is blank.
VLAN ID 1 always has a name of Default.
10. T
o add a new VLAN to the switch, click the ADD button.
11. T
o delete a selected VLAN from the switch, click the DELETE button.
The following table describes the nonconfigurable information displayed on the screen.
Table 36. VLAN Configuration
Field Description
VLAN Type This field identifies the type of the VLAN that you are configuring. You
cannot change the type of the default VLAN (VLAN ID = 1): it is always
type 'Default'. When you create a VLAN, using this screen, its type is
always Static.
A VLAN that is created by GVRP registration initially has
a type of Dynamic. When configuring a dynamic VLAN, you can change
its type to 'Static'.
Reset VLAN Configuration
 To reset VLAN configuration:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
