Configure System Information
98
M4100 Series Managed Switch
View LLDP Remote Device Inventory
 To view LLDP remote device inventory:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select System
 LLDP  LLDP  Remote Device Inventory.
The following table describes the LLDP Remote Device Inventory fields.
Table 28. LLDP remote device inventory
Field Description
Port Specifies the list of all the ports on which LLDP frame is enabled.
Remote Device ID Specifies the remote device ID.
Management Address Specifies the advertised management address of the remote system.
MAC Address Specifies the MAC address associated with the remote system.
System Name Specifies model name of the remote device.
Remote Port ID Specifies the port component associated with the remote system.
