NETGEAR M4100 Series User Manual

Table 72. DiffServ Configuration
Field Description
DiffServ Admin Mode The options mode for DiffServ. The default value is Enable. While
disabled, the Dif
fServ configuration is retained when saved and can be
changed, but it is not activated. When enabled, Diffserv services are
activated.
Class table Displays the number of configured DiffServ classes out of the total
allowed on the switch.
Class Rule table Displays the number of configured class rules out of the total allowed
on the switch.
Policy table Displays the number of configured policies out of the total allowed on
the switch.
Policy Instance table Displays the number of configured policy class instances out of the total
allowed on the switch.
Policy Attributes table Displays the number of configured policy attributes (attached to the
policy class instances) out of the total allowed on the switch.
Service table Displays the number of configured services (attached to the policies on
specified interfaces) out of the total allowed on the switch.
Configure Quality of Service
245
M4100 Series Managed Switch
Configure the Global Diffserv Mode
Packets are filtered and processed based on defined criteria. The filtering criteria are defined
by a class. The processing is defined by a policy's attributes. Policy attributes can be defined
on a per-class instance basis, and it is these attributes that are applied when a match occurs.
The configuration process begins with defining one or more match criteria for a class. Then
one or more classes are added to a policy
. Policies are then added to interfaces.
Packet processing begins by testing the match criteria for a packet. The all class type option
defines that each match criteria within a class must evaluate to true for a packet to match that
class. The any class type option specifies that at least one match criteria must evaluate to
true for a packet to match that class. Classes are tested in the order in which they were
added to the policy. A policy is applied to a packet when a class match within that policy is
found.
 To configure the global DiffServ mode:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
