NETGEAR M4100 Series User Manual

Configure System Information
80
M4100 Series Managed Switch
The following table describes the PoE Configuration nonconfigurable fields.
Table 23. Advanced PoE Configuration
Field Description
Units Displays the Current PoE Unit. You can change the PoE Unit by
selecting another unit ID listed here.
Firmware Version Version of the PoE controller's FW image.
Power Status Indicates the power status.
Total Power (Main AC) Displays the total power provided by the MAIN AC power source.
Total Power (RPS) Displays the total power provided by the redundant power source.
Power Source Current source of system power (Main AC or RPS).
Threshold Power System can power up one port, if consumed power is less than this
power
. That is, consumed power can be between Nominal and
Threshold Power values. The threshold power value is effected by
changing System Usage Threshold.
Consumed Power Total amount of a power that is currently being delivered to all ports.
Configure a PoE Port
 To configure a PoE port:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
