Routing
229
M4100 Series Managed Switch
The following table describes the nonconfigurable information displayed on the screen.
Table 70. ARP Cache
Field Description
Port The associated Unit/Slot/Port of the connection
IP Address Displays the IP address. It must be the IP address of a device on a
subnet attached to one of the switch's existing routing interfaces.
MAC Address The unicast MAC address of the device. The address is six two-digit
hexadecimal numbers separated by colons, for example,
00:06:29:32:81:40.
View or Configure the ARP Table
 To view or configure the ARP table:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
