NETGEAR M4100 Series User Manual

Configure System Information
83
M4100 Series Managed Switch
Configure SNMP Community Settings
By default, two SNMP Communities exist that use the SNMP V1 and SNMP V2 protocol:
• Private, with Read/Write privileges and status set to Enable.
• Public, with read-only privileges and status set to Enable.
These are well-known communities. You can change the default settings or add other
communities. Only the defined communities can access the switch using the SNMP V1 and
SNMP V2 protocols. Only those communities with read/write access can be used to change
the configuration using SNMP.
For information about using SNMP v3, see Configure SNMP v3 Settings for a User on
page 88.
 To configure SNMP community settings:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
Status The status is the operational status of the port PD detection.
• Disabled. No power being delivered.
• DeliveringPower. Power is being drawn by the device.
• Fault. Indicates a problem with the port.
• Test. The port is in test mode.
• otherFault. The port is idle due to an error condition.
• Searching. The port is not in one of the above states.
Fault Status Describes the error description when the PSE port is in fault status. No
Error indicates that the PSE port is not in any error state. MPS Absent
indicates that the PSE port has detected an absence of main power
supply. Short indicates that the PSE port has detected a short circuit
condition. Overload indicates that the PD connected to the PSE port
had tried to provide more power than is permissible by the hardware.
Power Denied indicates that the PSE port was denied power because
of a shortage of power or due to administrative action.
Table 24. PoE Port Configuration (continued)
Field Description
