GENERAL
M6060, M7060, WSM
G-102
10. IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by
KUBOTA. Use with implements which exceed the maximum specifications listed below, or which are otherwise unfit
for use with the KUBOTA Tractor may result in malfunctions or failures of the tractor, damage to other property and
injury to the operator or others. [Any malfunctions or failures of the tractor resulting from use with improper implements
are not covered by the warranty.]
• Implement size may vary depending on soil operating conditions.
• Strictly follow the instructions outlined in the operator's manual of the mounted or trailed machinery or
trailer, and do not operate the combination tractor - machine or tractor - trailer unless all instructions have
been followed
• Forestry Application
Following hazards exist;
a) toppling trees, primarily in case a rear-mounted tree grab-crane is mounted at the rear of the tractor;
b) penetrating objects in the operator's enclosure, primarily in case a winch is mounted at the rear of the
tractor.
Optional equipments such as OPS (Operator Protective Structure), FOPS (Falling Object Protective
Structure), etc. to deal with these hazards and other related hazards are not available for this tractor.
Without such optional equipment use is limited to tractor specific applications like transport and
stationary work.
9Y1210828GEG0139US0
Tread (max. width)
Lower link end max. loading
weight W0
Front Rear
1584 mm (62.36 in.) 1733 mm (68.23 in.) 2300 kg (5071 lbs)
Actual figures
Implement Weight W1 and / or
size
Max. Drawbar Load W2
Trailer loading weight W3
Max. capacity
As in the following list (shown on the next page)
Lower link end max. hydraulic lifting capacity W0
Implement weight W1: The implement's weight which can be put on the lower link
Max. drawbar load W2
Trailer loading weight W3: The max. loading weight for trailer (without trailer's weight)
