BRAKES
M6060, M7060, WSM
4-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-15.)
9Y1210828BRS0003US0
Item N·m kgf·m lbf·ft
Bleeder 6.5 to 6.8 0.66 to 0.70 4.8 to 5.0
Brake pipe retaining nut 16.0 to 24.0 1.6 to 2.5 11.8 to 17.7
Master cylinder pipe and return pipe retaining nut 49 to 68 5.0 to 7.0 37 to 50
Master cylinder hose and return hose retaining nut 23 to 27 2.3 to 2.8 17 to 20
Plug 98.1 to 117 10.0 to 12.0 72.4 to 86.7
To Next Page
