ENGINE
M6060, M7060, WSM
1-S9
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : Refer to "5. TIGHTENING TORQUES" on page G-15.)
Item N·m kgf·m lbf·ft
Muffler mounting nut 49.0 to 55.9 5.00 to 5.70 36.2 to 41.2
Filter comp (DPF) mounting screw 49.0 to 63.7 5.00 to 6.49 36.2 to 46.9
Temperature sensor (DPF) 25 to 34 2.5 to 3.5 18 to 25
Differential pressure pipe 16 to 22 1.6 to 2.3 12 to 16
Power steering hose retaining nut 22.6 to 27.5 2.3 to 2.8 16.6 to 20.3
Engine and clutch housing mounting screw and nut
(M14, 7T)
124 to 147 12.6 to 15.0 91.2 to 108
Front frame mounting screw (M14, 9T, UBS) 166.7 to 196.1 17.0 to 19.99 123.0 to 144.6
Item
Dimension ×
Pitch
N·m kgf·m lbf·ft
Glow lead mounting nut M4 × 0.7 0.98 to 1.7 0.10 to 0.18 0.73 to 1.3
Glow plug M8 × 1.0 7.7 to 9.3 0.78 to 0.95 5.7 to 6.8
Cylinder head cover screw M6 × 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
Injection pipe retaining nut M12 × 1.5 30 to 40 3.1 to 4.0 23 to 29
Oil switch taper screw R1/8 15 to 19 1.5 to 2.0 11 to 14
EGR cooler flange screw 24 to 27 2.4 to 2.8 18 to 20
Common rail mounting screw M8 × 1.25 24 to 27 2.4 to 2.8 18 to 20
Injection pipe retaining nut M14 × 1.5 30 to 40 3.1 to 4.0 23 to 29
Overflow pipe joint screw (Cylinder
head side) M8
M8 11 to 15 1.2 to 1.5 8.2 to 11
Overflow pipe joint screw (Common rail
side) M10
M10 7.9 to 12 0.80 to 1.3 5.8 to 9.4
Overflow pipe joint screw (Supply pump
side) M10
M10 7.9 to 12 0.80 to 1.3 5.8 to 9.4
Coolant Temperature Sensor 16 to 19 1.6 to 2.0 12 to 14
Camshaft position sensor mounting
screw
8.0 to 12 0.82 to 1.2 5.9 to 8.8
Crankshaft position sensor mounting
screw
8.0 to 12 0.82 to 1.2 5.9 to 8.8
Intake air temperature sensor 30 to 39 3.0 to 4.0 22 to 28
Boost sensor mounting screw M6 × 1.0 4 to 5 0.4 to 0.6 3 to 4
Injector clamp nut M8 × 1.25 24 to 27 2.4 to 2.8 18 to 20
Overflow pipe joint screw (M6 × 1.0) M6 × 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
Rocker arm bracket screw M10 × 1.25 49 to 55 5.0 to 5.7 37 to 41
*Cylinder head mounting screw M14 × 1.5 187 to 196 19.0 to 20.0 138 to 144
Exhaust manifold mounting nut M8 × 1.25 30 to 34 3.0 to 3.5 22 to 25
Supply pump mounting nut M14 × 1.5 24 to 27 2.4 to 2.8 18 to 20
Supply pump gear mounting nut M8 × 1.25 59 to 68 6.0 to 7.0 44 to 50
Mounting screw of crankshaft position
pulsar gear
M6 × 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
*Crankshaft screw M16 × 1.5 255 to 274 26.0 to 28.0 188 to 202
