TRANSMISSION
M6060, M7060, WSM
2-S6
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-15.)
9Y1210828TRS0122US0
Item N·m kgf·m lbf·ft
Clutch wire cable retaining nut 23.5 to 27.5 2.40 to 2.80 17.4 to 20.2
Rear wheel mounting nut 260 to 304 26.5 to 31.0 191.8 to 224.2
Shuttle valve pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Shuttle valve mounting screw 23.5 to 27.5 2.4 to 2.8 17.4 to 20.2
Joint screw for hydraulic pipe 29.4 to 34.3 3.0 to 3.5 21.7 to 25.3
Power steering hose retaining nut 22.6 to 27.5 2.3 to 2.8 16.6 to 20.3
ROPS under frame mounting screw (M16, 9T) 260 to 304 26.5 to 31.0 192 to 224
Seat mounting nut 17.7 to 20.6 1.81 to 2.10 13.1 to 15.2
Seat bracket mounting screw 48.1 to 55.9 4.91 to 5.70 35.5 to 41.2
3-point hitch delivery pipe 2 retaining nut 107.9 to 117.7 11.0 to 12.0 79.6 to 86.8
Power steering pipe and hydraulic pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Transmission case and clutch housing mounting screw,
nut (M10, 9T)
60.8 to 70.5 6.2 to 7.2 44.9 to 52.1
Transmission case and clutch housing mounting screw,
nut (M14, 9T)
166.7 to 196.1 17.0 to 20.0 123.0 to 144.6
Cylinder hose retaining nut 34.3 to 48.1 3.5 to 4.9 25.3 to 35.4
3-point hitch hydraulic block mounting screw 166.7 to 196.1 17.0 to 20.0 123.0 to 144.3
3-point hitch hydraulic block mounting nut 123.6 to 147.1 12.61 to 15.00 91.17 to 108.4
PTO gear case mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Damper disc mounting screw 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Shuttle case mounting screw and nut 48.1 to 55.9 4.9 to 5.7 35.4 to 41.2
Shift cover mounting screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Creep gear cover 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
PTO clutch holder mounting screw 23.5 to 27.4 2.4 to 2.8 17.4 to 20.3
Differential bearing support mounting screw 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
Spiral bevel gear mounting UBS screw 142.2 to 161.8 14.5 to 16.5 104.9 to 119.3
PTO shaft staking nut 225.5 to 264.8 23 to 27 166.4 to 195.3
PTO gear case mounting screws and reamer screw 77.5 to 90.2 7.9 to 9.2 57.1 to 66.5
Spiral bevel pinion shaft staking nut 117.7 12.0 86.8
