GENERAL
M6060, M7060, WSM
G-108
[2] FRONT LOADER
Fixation points on the body of the tractor where the front loader
must be installed.
Install the front loader frame to the clutch housing and the front
axle frame as shown.
To avoid personal:
• Special attention should be made when lifting the load,
keep the bucket correctly positioned to prevent spillages.
• Not all risks are listed.
Refer to front loader operator's manual.
9Y1210828GEG0143US0
M6060, M7060
(1)
Size-length M20-60 bolt
Strength division 8.8 Approx. SAE GR5
Number of pieces 16
Spring lock washers M20
Hardened plain washers 3/4
Tightening torque 367.8 N·m (37.51 kgf·m, 271.3 lbf·ft)
(1) Bolt
