BRAKES
M6060, M7060, WSM
4-S2
2. SERVICING SPECIFICATIONS
TRAVELING BRAKE
9Y1210828BRS0002US0
Item Factory Specification Allowable Limit
Brake Pedal R.H. and L.H. (F12/R12) Free Travel
Stroke
7 to 14 mm
0.3 to 0.6 in.
Less than
100 mm
3.9 in.
–
–
Equalizer Working Level Level Difference
between Both
Pedals
Over
5 mm
0.2 in.
–
Brake Rod Length 95 mm
3.7 in.
–
Brake Pedal Bushing to Pedal Shaft
• Brake Pedal Bushing
• Pedal Shaft
Clearance
I.D.
O.D.
0.0300 to 0.246 mm
0.00119 to 0.00968 in.
25.030 to 25.146 mm
0.98544 to 0.99000 in.
24.9 to 25.0 mm
0.981 to 0.984 in.
0.5 mm
0.02 in.
–
–
Brake Piston Flatness – 0.3 mm
0.01 in.
Brake Disk Thickness 4.15 to 4.35 mm
0.164 to 0.171 in.
3.3 mm
0.13 in.
Brake Plate Thickness 2.1 to 2.5 mm
0.083 to 0.098 in.
1.5 mm
0.059 in.
Cam Plate Flatness – 0.30 mm
0.012 in.
Cam Plate and Ball Height 25.45 to 45.55 mm
1.002 to 1.0059 in.
25.00 mm
0.9843 in.
KiSC issued 08, 2013 A
