REAR AXLE
M6060, M7060, WSM
3-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-15.)
9Y1210828RAS0003US0
Item N·m kgf·m lbf·ft
Rear wheel mounting nut 344 to 392 35.0 to 40.0 254 to 289
ROPS under frame mounting screw (M16, 9T) 260 to 304 26.5 to 31.0 192 to 224
Rear axle case mounting screw and nut 197 to 225 20.0 to 23.0 145 to 166
Stabilizer bracket mounting screw (M16, 9T) 260 to 304 26.5 to 31.0 192 to 224
Cabin mounting bolt and nut (M14, 7T) 124 to 147 12.6 to 15.0 91.2 to 108
Retainer mounting screw 60.8 to 70.6 6.2 to 7.2 44.9 to 72.3
