STEERING
M6060, M7060, WSM
6-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : Refer to "5. TIGHTENING TORQUES" on page G-15.)
9Y1210828STS0003US0
Item N·m kgf·m lbf·ft
Rear wheel mounting nut 260 to 304 26.5 to 31.0 191.8 to 224.2
3-point hitch delivery pipe retaining nut 107.9 to 117.7 11.0 to 12.0 79.6 to 86.8
Steering wheel mounting nut 48.1 to 55.9 4.91 to 5.70 35.5 to 41.2
Power steering delivery hose retaining nut 22.6 to 27.5 2.3 to 2.8 16.6 to 20.3
Controller pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Oil cooler pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Power steering controller mounting screw 48.1 to 55.8 4.9 to 5.7 35.5 to 41.2
Power steering pipe retaining nut 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
Power steering joint shaft mounting screw 23.5 to 27.4 2.4 to 2.8 17.4 to 20.3
Power steering delivery hose 22.6 to 27.5 2.3 to 2.8 16.6 to 20.3
Tie-rod end slotted nut 156.8 to 176.4 15.99 to 17.98 115.7 to 130.1
Tie-rod joint 166.7 to 196.1 17.0 to 20.0 123.0 to 144.7
Hose joint 29.4 to 34.3 3.0 to 3.5 21.7 to 25.3
Housing cover mounting screw 39.2 to 44.1 4.0 to 4.5 28.9 to 32.5
Gerotor assembly mounting screw (5/16') 25.5 to 28.4 2.6 to 2.9 18.8 to 21.0
