FRONT AXLE
M6060, M7060, WSM
5-S4
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : Refer to "5. TIGHTENING TORQUES" on page G-15)
[4WD]
9Y1210828FAS0003US0
Item N·m kgf·m lbf·ft
Tie-rod end lock nut 167 to 196 17.0 to 20.0 123 to 144
Front axle rocking force adjusting screw 20 to 29 2.0 to 3.0 15 to 21
Front axle rocking force adjusting lock nut 98.1 to 147 10.0 to 15.0 72.4 to 108
Power steering hose retaining nut 23 to 27 2.3 to 2.8 17 to 20
Front wheel mounting nut (M16) 260 to 304 26.5 to 31.0 192 to 224
Bracket mounting nut 124 to 147 12.6 to 15.0 91.2 to 108
Bracket mounting screw 167 to 196 17.0 to 20.0 123 to 144
Tie-rod end slotted nut 157 to 176 16.0 to 18.0 116 to 130
Tie-rod joint lock nut 167 to 196 17.0 to 20.0 123 to 144
Knuckle arm mounting screw (M12) 78 to 90 7.9 to 9.2 58 to 66
Bevel gear case mounting screw (M16, 9T) 260 to 304 26.5 to 31.0 192 to 224
Front wheel case support mounting screw (M16, 9T) 260 to 304 26.5 to 31.0 192 to 224
Front wheel case cover mounting screw 48 to 55 4.9 to 5.7 36 to 41
Front wheel mounting stud bolt (M16) 131 to 152 13.3 to 15.5 96.2 to 112
Differential case cover mounting screw (M8, 9T) 30 to 34 3.0 to 3.5 22 to 25
To Next Page
