ELECTRICAL SYSTEM
M6060, M7060, WSM
8-S28
(6) Selecting Tractor Specification
Preparation
1. Set the mode item "SEL-1" to "SEL-4".
2. Check each "Specification Table".
9Y1210828ELS0048US0
Select the Tractor Model (SEL-1)
1. Set the mode item "SEL-1".
2. Make sure that the mode item "SEL-1" blinks on the display
with press and hold the traveling speed select switch until
"TYPE-1" appears on the display.
3. Each time the traveling speed select switch is pressed, the code
change in order of "1" → "2" → "3" → "4" → "1". Select the
appropriate code according to the table in last page.
4. Turn the key switch to "OFF" position to exit.
4th/6th: Main gear range
H/L: Sub gear range (High/Low)
C: Creep (If equipped)
9Y1210828ELS0049US0
Model specifications
Display Specifications
TYPE
1 North America
3EURO model
DT·Bi-Speed
Display Specifications
2WD 2WD
4WD 4WD
Main and sub gear
Display Specifications
1 4th, H/L
2 4th, H/L, C
3 6th, H/L
5 6th, H/L, C
To Next Page
