TRANSMISSION
M6060, M7060, WSM
2-S11
[3] GEAR SHIFTING LINKAGE
(1) Main Gear Shift
Checking Function of Main Gear Shift
1. Check the function of the main gear shift.
• Neutral position to 1st gear position.
• Neutral position to 2nd gear position.
• Neutral position to 3rd gear position.
• Neutral position to 4th gear position.
• Neutral position to 5th gear position.
• Neutral position to 6th gear position.
2. If shifting is not smooth, adjust the main gear shift following
pages.
9Y1210828TRS0006US0
(a) Select 1st-2nd Gear Shift Position
(b) Select 3rd-4th Gear Shift Position
(c) Select 5th-6th Gear Shift Position
(d) Engage to 1st or 3rd or 5th Gear
Position
(e) Engage to 2nd or 4th or 6th Gear
Position
KiSC issued 08, 2013 A
