ELECTRICAL SYSTEM
M6060, M7060, WSM
8-S31
Block Heater (SEL-4)
1. Set the mode item "SEL-4".
2. Make sure that the mode item "SEL-4" blinks on the display
with press and hold the traveling speed select switch until
"ENG-0" appears on the display.
3. Each time the traveling speed select switch is pressed, the code
change in order of "0" → "1" → "0". Select the appropriate
code according to the table.
9Y1210828ELS0052US0
[8] TRACTOR ECU
(1) Tractor ECU
Tractor ECU (ROPS Model)
1. Remove the OPC connector.
2. Remove the seat (1).
9Y1210828ELS0053US0
Block Heater
Display Specifications
ENG
0 Without Block Heater
1 With Block Heater
(1) LCD Monitor
(1) Seat (2) Tractor ECU
To Next Page
