wsm M6060 User Manual

ELECTRICAL SYSTEM
M6060, M7060, WSM
8-S6
2. SERVICING SPECIFICATIONS
STARTER MOTOR
ALTERNATOR
FUEL LEVEL SENSOR
COOLANT TEMPERATURE SENSOR
FLASHER UNIT
SOLENOID VALVE
4WD ON-OFF SWITCH
9Y1210828ELS0002US0
Item Factory Specification Allowable Limit
Commutator O.D. 32.0 mm
1.26 in.
31.4 mm
1.24 in.
Mica Undercut 0.50 to 0.80 mm
0.020 to 0.031 in.
0.2 mm
0.0079 in.
Brush Length 18.0 mm
0.709 in.
11.0 mm
0.433 in.
Item Factory Specification Allowable Limit
Slip Ring O.D. 22.7 mm
0.894 in.
22.1 mm
0.870 in.
Brush Length 18.5 mm
0.728 in.
5.0 mm
0.20 in.
Item Factory Specification Allowable Limit
Float at Uppermost Position Resistance 3.0 to 5.0 Ω –
Float at Lowermost Position Resistance 107.5 to 112 Ω –
Item Factory Specification Allowable Limit
Coolant Temperature at 110 °C (230 °F) Resistance Approx. 141.7 Ω –
Coolant Temperature at 80°C (176 °F) Resistance Approx. 318 Ω –
Coolant Temperature at 20 °C (68 °F) Resistance Approx. 2.45 kΩ –
Coolant Temperature at −20 °C (−4 °F) Resistance Approx. 15.04 kΩ –
Item Factory Specification Allowable Limit
Flasher Blinking Times 60 to 120 times / minutes –
Item Factory Specification Allowable Limit
PTO Solenoid Valve Resistance 10 to 12 Ω –
Item Factory Specification Allowable Limit
4WD Switch Setting Length 10.0 to 11.5 mm
0.394 to 0.452 in.
–
KiSC issued 08, 2013 A
