TRANSMISSION
M6060, M7060, WSM
2-S3
2. SERVICING SPECIFICATIONS
Item Factory Specification Allowable Limit
Clutch Pedal Free Travel
Total St r o ke
15 to 20 mm
0.59 to 0.79 in.
145 to 155 mm
5.71 to 6.10 in.
–
–
Main Shift Rod 1 (ROPS Model) Length 135 mm
5.31 in.
–
Main Shift Rod 2 (ROPS Model) Length 179 mm
7.05 in.
–
Main Shift Rod 1 (CABIN Model) Length 192 mm
7.56 in.
–
Main Shift Rod 2 (CABIN Model) Length 209 mm
8.23 in.
–
Shuttle Clutch Valve
Condition
• Engine Speed : 2400 min
-1
(rpm)
• Oil temperature :
45 to 55 °C (113 to 131 °F)
Operating
Pressure
2.16 to 2.25 MPa
20.0 to 23.0 kgf/cm
2
313 to 327 psi
–
2WD-4WD Clutch Valve
Condition
• Engine Speed : 2400 min
-1
(rpm)
• Oil temperature :
45 to 55 °C (113 to 131 °F)
Operating
Pressure
1.97 to 2.15 MPa
20.0 to 22.0 kgf/cm
2
265 to 312 psi
–
PTO Clutch Valve
Condition
• Engine Speed : 2400 min
-1
(rpm)
• Oil temperature :
45 to 55 °C (113 to 131 °F)
Operating
Pressure
1.97 to 2.15 MPa
20.0 to 22.0 kgf/cm
2
265 to 312 psi
–
Hand Accelerator Lever (ROPS Model) Operating Force 10 to 30 N
1.1 to 3.0 kgf
2.3 to 6.7 lbf
–
Hand Accelerator Lever (CABIN Model) Operating Force 10 to 30 N
1.1 to 3.0 kgf
2.3 to 6.7 lbf
–
Accelerator Wire (CABIN Model) Length 0 to 5 mm
0 to 0.1 in.
–
External Circlip to Collar on 1st Shaft Clearance 0.2 mm
0.0078 in.
or less
–
Shift Fork to Shift Groove (for Main Change
Section and Range Section)
Clearance 0.15 to 0.40 mm
0.0059 to 0.0157 in.
0.80 mm
0.031 in.
Damper Disc Boss to Shaft Backlash
(Displacement
Around Disc Edge)
– 2.0 mm
0.079 in.
KiSC issued 08, 2013 A
