ELECTRICAL SYSTEM
M6060, M7060, WSM
8-S2
GLOW
LIGHTING SYSTEM
Symptom Probable Cause Solution
Reference
Page
Glow Does Not Heat Slow blow fuse blown Replace 8-S10,
8-S12
Glow relay damaged Replace 8-S43
Glow damaged Replace 8-S17
Symptom Probable Cause Solution
Reference
Page
Head Light Does Not
Light
Fuse blown Replace 8-S10,
8-S11
Bulb blown Replace G-49
Wiring harness disconnected or improperly
connected
Repair or replace –
Illumination Light
Does Not Light
Fuse blown Replace 8-S10,
8-S11
Meter panel damaged Replace G-49
Wiring harness disconnected or improperly
connected
Repair or replace –
Tail Light Does Not
Light
Fuse blown Replace 8-S10,
8-S11
Wiring harness disconnected or improperly
connected
Repair or replace –
Hazard Light Does
Not Light
Fuse blown Replace 8-S10,
8-S11
Bulb blown Replace G-49
Flasher unit damaged Replace 8-S49
Hazard switch damaged Replace 8-S48
Turn signal switch damaged Replace 8-S46,
8-S47
Hazard and Turn
Signal Indicator
Lamp Does Not Light
Meter panel damaged Replace 8-S22
Wiring harness disconnected or improperly
connected
Repair or replace –
Hazard and Turn
Signal Light Does Not
Go ON and OFF
Flasher unit damaged Replace 8-S49
Work Light Does Not
Light
Fuse blown Replace 8-S10,
8-S11
Bulb blown Replace G-49
Wiring harness disconnected or improperly
connected
Repair or replace –
Brake Light Does Not
Light
Fuse blown Replace 8-S10,
8-S11
Bulb blown Replace G-49
KiSC issued 08, 2013 A
