CABIN

M6060, M7060, WSM

9-M5

[5] AIR FLOW

Flow

Air in the cabin and fresh air introduced into the cabin

flow as shown below. Adjust the 7 air ports to obtain the

desired condition.

IMPORTANT

• Do not pour water directly into the fresh air port

while washing the vehicle.

9Y1210828CAM0009US0

[6] AIR CONTROL VENT

Dashboard Air Outlet

The dashboard air outlet can be independently

adjusted as required.

9Y1210828CAM0010US0

(1) Defroster Air Outlet

(2) Dashboard Air Outlet

(3) Control Panel

(4) Inner Air Filter

(5) Fresh Air Filter

(a) Inner Air Recirculation

(b) Fresh Air Inlet

(1) Face Area Air Outlet

(2) Back Area Air Outlet

(3) Feet Area Air Outlet

(4) Back Area Air Outlet

(A) Open

(B) Shut
