ENGINE
M6060, M7060, WSM
1-S22
(Continued)
(When reassembling)
CAUTION
• When you install the temperature sensors, be sure that the
temperature sensors are installed to the original positions.
IMPORTANT
• Replacing the gaskets (13), (15), (16) with new ones.
• If the differential pressure tube is damaged or cracked,
replace it.
• When the differential pressure pipe (4), (6) and temperature
sensor (12), (14), (17) is removed, wipe off the anti-seize &
lubricating compound, apply a anti-seize & lubricating
compound (Bostik, NEVER SEEZ, Pure Nickel Special
Grade), and then attach them to their correct position.
• When replacing the differential pressure pipe (4), (6) apply
a anti-seize & lubricating compound (Bostik, NEVER SEEZ,
Pure Nickel Special Grade), and then attach it to its correct
position.
• When replacing the temperature sensor, check that it is
coated with anti-seize & lubricating compound, and then
attach it to its correct position.
• Tighten bolts and nuts to their specified torque. Also
tighten the temperature sensor tightening nut or the
differential pressure pipe tightening nut to the specified
torque with crowfoot wrench.
• After attaching the assembly, start the engine and make
sure that there are no gas leaks.
• Reassemble the filter comp (DPF) (9) in the correct
direction.
9Y1210828ENS0021US0
(3) Lubricant and Coolant
Draining Engine Oil and Coolant
• See page G-22 and G-40.
9Y1210828ENS0022US0
Tightening torque
Filter comp (DPF) mounting
screw
49.0 to 63.7 N·m
5.00 to 6.49 kgf·m
36.2 to 46.9 lbf·ft
Temperature sensor
25 to 34 N·m
2.5 to 3.5 kgf·m
18 to 25 lbf·ft
Differential pressure pipe
16 to 22 N·m
1.6 to 2.3 kgf·m
12 to 16 lbf·ft
(1) Filter Comp (DPF) Mounting Screw
(2) Filter Comp (DPF) Mounting Screw
(3) Tube
(4) Differential Pressure Pipe
(5) Tube
(6) Differential Pressure Pipe
(7) Differential Pressure Sensor
(8) Body (DPF Outlet)
(9) Filter Comp (DPF)
(10) Collar (DPF)
(11) Catalyst (DOC)
(12) Temperature Sensor (T
0
)
(13) Gasket
(14) Temperature Sensor (T
1
)
(15) Gasket
(16) Gasket
(17) Temperature Sensor (T
2
)
