FRONT AXLE
M6060, M7060, WSM
5-S2
2. SERVICING SPECIFICATIONS
[4WD]
Item Factory Specification Allowable Limit
Toe-in 2.0 to 8.0 mm
0.079 to 0.31 in.
–
Front Wheel Axial Sway
(Face Runout of
Wheel at Bead)
Less than
5.0 mm
0.20 in.
–
Bevel Gear Case to Stopper Clearance Below
0.5 mm
0.02 in.
–
Bevel Gear to Bevel Pinion Shaft Backlash 0.20 to 0.30 mm
0.0079 to 0.011 in.
0.4 mm
0.02 in.
Differential Case to Differential Side Gear
• Differential Case Bore
• Differential Side Gear Boss
Clearance
I.D.
O.D.
0.050 to 0.091 mm
0.0020 to 0.0035 in.
32.025 to 32.050 mm
1.2609 to 1.2618 in.
31.959 to 31.975 mm
1.2583 to 1.2588 in.
0.35 mm
0.014 in.
–
–
Differential Pinion Shaft to Pinion Gear
• Differential Pinion Shaft
• Differential Pinion Gear
Clearance
O.D.
I.D.
0.016 to 0.052 mm
0.00063 to 0.0020 in.
15.966 to 15.984 mm
0.62859 to 0.62929 in.
16.000 to 16.018 mm
0.62993 to 0.63062 in.
0.25 mm
0.0098 in.
–
–
Pinion Gear to Differential Side Gear Backlash 0.1 to 0.3 mm
0.004 to 0.01 in.
0.4 mm
0.02 in.
Pinion Gear to LSD Side Gear Backlash 0.1 to 0.3 mm
0.004 to 0.01 in.
0.4 mm
0.02 in.
LSD Disk Slip Torque 54 to 67 N·m
5.5 to 6.9 kgf·m
40 to 49 lbf·ft
–
Front Bracket to Rear Bracket Bushing
• Rear Differential Case Boss
• Front Differential Case Boss
Alloy Thickness
O.D.
O.D.
0.57 mm
0.022 in.
109.965 to 110.000 mm
4.32933 to 4.33070 in.
79.965 to 80.000 mm
3.1483 to 3.1496 in.
–
–
–
Front Wheel Case Support Bushing
• Bearing Retainer
Alloy Thickness
O.D.
0.57 mm
0.022 in.
59.97 to 60.00 mm
2.361 to 2.362 in.
–
–
Front Wheel Case Bushing
• Bevel Gear Case
Alloy Thickness
O.D.
0.57 mm
0.022 in.
59.97 to 60.00 mm
2.361 to 2.362 in.
–
–
KiSC issued 08, 2013 A
