wsm M6060 User Manual

REAR AXLE
M6060, M7060, WSM
3-S2
2. SERVICING SPECIFICATIONS
9Y1210828RAS0002US0
Item Factory Specification Allowable Limit
Internal Gear to Planetary Gear Backlash 0.2 to 0.4 mm
0.008 to 0.01 in.
0.5 mm
0.02 in.
Thrust Collar Thickness 1.55 to 1.65 mm
0.0611 to 0.0649 in.
1.2 mm
0.047 in.
Planetary Gear to Planetary Gear Shaft
• Planetary Gear Shaft
• Planetary Gear
• Needle
Clearance
O.D.
I.D.
O.D.
0.0090 to 0.048 mm
0.00036 to 0.0018 in.
29.991 to 30.000 mm
1.1808 to 1.1811 in.
42.009 to 42.025 mm
1.6539 to 1.6545 in.
5.994 to 6.000 mm
0.2360 to 0.2362 in.
0.3 mm
0.01 in.
–
–
–
