A:184 AK 98 Dialysis Machine - Technical data and specifications
HCEN12745 Revision 10.2016
Program version 2.xx
Power consumption Max. 2025 W at 230 V
Max. 1575 W at 115 V
Cable 3 conductor cable, Length max. 3.5 m
Ratings: 230 - 250 V AC 10 A or 110 - 125 V AC 15 A
External fuses For 115 V AC, 2 x T15AH for heater
For 230 V AC, 2 x T10AH for heater
Mains plug Earthed plug, 250 V AC / 10 A
Earthed plug, 125 V AC / 15 A Hospital grade
Earth leakage current max 500 Ī¼A
Patient leakage
current
max 100 Ī¼A AC
max 10 Ī¼A DC
All leakage currents specified are without external equipment connected to the AK 98
dialysis machine.
14.1.18 Network connection
Cable Network cable shall be of type Cat5e shielded cable. Shielding shall
be F/UTP, S/UTP or SF/UTP
14.1.19 Connection of external equipment
External connector To communicate via the external connector 25 pin D-Sub as USB, a
virtual COM port driver (VCD) needs to be installed on your PC.
External equipment
Additional equipment connected to medical electrical equipment shall comply with the
respective IEC or ISO standards (e.g. IEC 60950 for data processing equipment).
Furthermore all configurations shall comply with the requirements for medical electrical
systems (see clause 16 of IEC 60601-1).
Anybody connecting additional equipment to medical electrical equipment configures a
medical system and is therefore responsible that the system complies with the
requirements for medical electrical systems. Attention is drawn to the fact that local
laws take priority over the above mentioned requirements. If in doubt, consult your
local Baxter Service representative or the technical service department.
Max voltage 24 V AC or DC
Max current 100 mA AC or DC
Max delay time 100 ms
Table 14-14. External alarm
USB type USB 2.0 mass storage device
Max input voltage Ā± 15 V DC
High level min output
voltage
5.0 V DC
Low level max output
voltage
- 5.0 V DC
Max output current Ā± 5 mA DC
Table 14-15. RS-232C
