6
D-STAR OPERATION <BASIC>
6-33
D Unlinkingareector
Before linking to another reflector, be sure to unlink the
current reflector.
Touch [DR]. q
Check whether or not “TO” is selected. w
• If “TO” is not selected, touch the “TO” eld.
Touch the “TO” field. e
• Opens the “TO SELECT” screen.
Touch “Reflector.” r
• Opens the “REFLECTOR” screen.
Touch “Unlink Reflector.” t
• The transceiver returns to the DR screen.
• “Unlink Reector” and “U” are displayed in “TO.”
Hold down [PTT] to unlink the reflector. y
• The LED1 on the microphone lights red.
Reflector operation (Continued)
D ReectorEchoTesting
This function is a useful check of how well your signal
is getting into the repeater, and you can use it to verify
that your repeater is operating normally.
Touch [DR]. q
Check whether or not “TO” is selected. w
• If “TO” is not selected, touch the “TO” eld.
Touch the “TO” field. e
• Opens the “TO SELECT” screen.
Touch “Reflector.” r
• Opens the “REFLECTOR” screen.
Touch “Echo Test.” t
• The transceiver returns to the DR screen.
• “Echo Test” and “E” are displayed in “TO.”
Hold down [PTT] and speak into the microphone. y
• The LED1 on the microphone lights red.
Release [PTT] to hear your message. u
