11
REPEA
TER AND DUPLEX OPERA
TIONS
11-5
Offbandindication
If
the
transmit
frequency
is
out
of
the
amateur
band,
the
off
band
indication,
“OFF
BAND
,
”
appears
on
the
dis-
pla
y when [PTT] is pushed.
Check the frequency offset
(p
.
11-4) or duplex direction (p
.
11-4) in this case.
Appears
